18" 20" Drum Fan Floor Fan
keywords:
hiddenValue
- Detail
-
18 inches Floor barrel fan 20 inches Floor barrel fan Feature: • 100% copper coil motor with fuse, durable ball-bearing • Painted black thick drum guard net • 3-blades aluminum propeller (powerful wind) 5-blades aluminum propeller (ultra-silent) • Thick drum guard net & aluminum blades make these fan fit for 8m wide-range air delivery • Stable floor pedestal with anti-slip rubber foot pads to ensure safety • 3 speeds rotary switch • 180° vertical tilt angle or 360° omni-direction tilt angle adjustable, freely control the swing head angle • Further more Backside power cord wrap for easy storage Handles on the rear guards allow you with easy moving
AIROTINA INDUSTRIAL FLOOR DRUM FAN
Floor Drum Fan is for powerful and centralized air cooling. 8m long distance air delivery offer you wide range airflow. Thick drum structure grill cage which brings more than 10m air delivery.
18" Drum Fan 18" Drum Fan 20" Drum Fan 20" Drum Fan 20" Drum Fan 20" Drum Fan Model FF-45 FF-45A FF-50 FF-50A FF-50B FF-50B1 Size Φ18 inch (45cms) Φ18 inch (45cms) Φ20 inch (50cms) Φ20 inch (50cms) Φ20 inch (50cms) Φ20 inch (50cms) Tilting Angle 180° 180° 180° 180° 180° 360° Input 110-120V, 60Hz 220-240V, 50Hz 220-240V, 60Hz 220-240V, 50 / 60Hz Power (Max.) 100W-115W 100W-115W 120W-140W 120W-140W 120W-140W 120W-140W Speeds (Max.) 1400rpm 1400rpm 1360rpm 1360rpm 1360rpm 1360rpm Air Volume (m3/min) 118 118 181 181 181 181 Air Flow (Max.) 4200 CFM 4200 CFM 6425 CFM 6425 CFM 6425 CFM 6425 CFM Packing Size (cm) 54X18X54.5 54X18X54.5 56.2X18X56.6 56.2X18X56.6 56.2X18X56.6 63.3X18.2X64.8 18" Drum Fan 20" Drum Fan 20" Drum Fan
Detail
AIROTINA INDUSTRIAL FLOOR DRUM FAN
Floor Drum Fan is for powerful and centralized air cooling. 8m long distance air delivery offer you wide range airflow. Thick drum structure grill cage which brings more than 10m air delivery.
|
|
|
|
|
|
|
|
| 18" Drum Fan | 18" Drum Fan | 20" Drum Fan | 20" Drum Fan | 20" Drum Fan | 20" Drum Fan | |
| Model | FF-45 | FF-45A | FF-50 | FF-50A | FF-50B | FF-50B1 |
| Size | Φ18 inch (45cms) | Φ18 inch (45cms) | Φ20 inch (50cms) | Φ20 inch (50cms) | Φ20 inch (50cms) | Φ20 inch (50cms) |
| Tilting Angle | 180° | 180° | 180° | 180° | 180° | 360° |
| Input | 110-120V, 60Hz | 220-240V, 50Hz | 220-240V, 60Hz | 220-240V, 50 / 60Hz | ||
| Power (Max.) | 100W-115W | 100W-115W | 120W-140W | 120W-140W | 120W-140W | 120W-140W |
| Speeds (Max.) | 1400rpm | 1400rpm | 1360rpm | 1360rpm | 1360rpm | 1360rpm |
| Air Volume (m3/min) | 118 | 118 | 181 | 181 | 181 | 181 |
| Air Flow (Max.) | 4200 CFM | 4200 CFM | 6425 CFM | 6425 CFM | 6425 CFM | 6425 CFM |
| Packing Size (cm) | 54X18X54.5 | 54X18X54.5 | 56.2X18X56.6 | 56.2X18X56.6 | 56.2X18X56.6 | 63.3X18.2X64.8 |
| 18" Drum Fan | 20" Drum Fan | 20" Drum Fan | |||
|
|
|
|||
