Industrial Pedestal Drum Fan
keywords:
hiddenValue
- Detail
-
18 inch Pedestal Drum Fan 20 inch Pedestal Drum Fan Feature: •100% copper coil motor with fuse, durable ball bearing • Painted black thick drum guard net fit for spot and long distance air cooling • Powerful wind with longer air delivery distance (7.2m/s air speed) • 3 / 5 Aluminum blades ( color can be customized ) • Adjustable height stand rod • 5KG Diameter 50cm Firm metal structure base or plastic stable round base • 3 speeds rotary switch • 180° vertical tilt or 360° omni-direction adjustable, freely control the swing head angle • Further more Backside power cord wrap for easy storage Handles on the rear guards allow you with easy moving
AIROTINA INDUSTRIAL PEDESTAL DRUM FAN
Powerful Industrial pedestal thicker drum stand fan is a stylish and excellent craft commercial / industrial fan.
180 degree adjustable vertical tilt head and adjustable fan height give you all-direction cooling.
This pedestal fan fit for spot and long distance air cooling, like: garages, home, workshops, warehouses.
18 inch 18 inch 20 inch 20 inch 20 inch 20 inch Model FS-45 FS-45A FS-50 FS-50A FS-50B FS-50B1 Size Φ18 inch (45cms) Φ18 inch (45cms) Φ20 inch (50cms) Φ20 inch (50cms) Φ20 inch (50cms) Φ20 inch (50cms) Tilting Angle 180° 180° 180° 180° 180° 180° (vertical)
& 180° (horizontal)
Input 110-120V, 60Hz 220-240V, 50Hz 220-240V, 60Hz 220-240V, 50 / 60Hz Power 100W-115W 100W-115W 120W-150W 120W-150W 120W-150W 120W-150W Speeds (Max.) 1400rpm 1400rpm 1360rpm 1360rpm 1360rpm 1360rpm Air Volume (m3/min) 118 113 177 158 177 177 Air Flow (Max.) 4200 CFM 4012 CFM 6250 CFM 5600 CFM 6250 CFM 6250 CFM Packing Size (cm) 54X24.2X54.5 54X24.2X54.5 58X24.2X59.3 58X24.2X59.3 58X24.2X59.3 63.5X25X63.5 18" Pedestal Fan 20" Pedestal Fan 20" Pedestal Fan (360 degree)
Detail
AIROTINA INDUSTRIAL PEDESTAL DRUM FAN
Powerful Industrial pedestal thicker drum stand fan is a stylish and excellent craft commercial / industrial fan.
180 degree adjustable vertical tilt head and adjustable fan height give you all-direction cooling.
This pedestal fan fit for spot and long distance air cooling, like: garages, home, workshops, warehouses.
|
|
|
|
|
|
|
| 18 inch | 18 inch | 20 inch | 20 inch | 20 inch | 20 inch | |
| Model | FS-45 | FS-45A | FS-50 | FS-50A | FS-50B | FS-50B1 |
| Size | Φ18 inch (45cms) | Φ18 inch (45cms) | Φ20 inch (50cms) | Φ20 inch (50cms) | Φ20 inch (50cms) | Φ20 inch (50cms) |
| Tilting Angle | 180° | 180° | 180° | 180° | 180° |
180° (vertical) & 180° (horizontal) |
| Input | 110-120V, 60Hz | 220-240V, 50Hz | 220-240V, 60Hz | 220-240V, 50 / 60Hz | ||
| Power | 100W-115W | 100W-115W | 120W-150W | 120W-150W | 120W-150W | 120W-150W |
| Speeds (Max.) | 1400rpm | 1400rpm | 1360rpm | 1360rpm | 1360rpm | 1360rpm |
| Air Volume (m3/min) | 118 | 113 | 177 | 158 | 177 | 177 |
| Air Flow (Max.) | 4200 CFM | 4012 CFM | 6250 CFM | 5600 CFM | 6250 CFM | 6250 CFM |
| Packing Size (cm) | 54X24.2X54.5 | 54X24.2X54.5 | 58X24.2X59.3 | 58X24.2X59.3 | 58X24.2X59.3 | 63.5X25X63.5 |
| 18" Pedestal Fan | 20" Pedestal Fan | 20" Pedestal Fan (360 degree) | |||
|
|
|
|||
