Industrial Portable Ventilator
keywords:
hiddenValue
- Detail
-
8 inches Industrial Portable Ventilator 10 inches Industrial Portable Ventilator 12inches Industrial Portable Ventilator 14 inches Industrial Portable Ventilator 16 inches Industrial Portable Ventilator • 100% copper coil motor with fuse, durable ball-bearing • Painted orange/ yellow/black metal enclosure, • Metal fan blades and Air Outlet, high speed and strong airflow • It used along with a flexible soft duct to circulate fresh air for high pressure air delivery under long distance • It for cabin, underground, cable maintenance, repairing tunnel project and so on
8" Ventilator 10" Ventilator 12" Ventilator 14" Ventilator 16" Ventilator Model SHT-20 SHT-25 SHT-30 APB-35 APB-40 Size Φ8inch (20cms) Φ10 inch (25cms) Φ12 inch (30cms) Φ14 inch (35cms) Φ16 inch (40cms) Input 110-127V, 60Hz 220-240V, 50Hz 220-240V, 50 / 60Hz Power (Max.) 230-250W 320-370W 520-550W 750-900W 1100-1200W Air Volume (m3/min) 25 43 65 82 96 Speeds (Max.) 2800rpm 2800rpm 2800rpm 2800rpm 2800rpm Air Flow (Max.) 882 CFM 1520 CFM 2300 CFM 2900 CFM 3400 CFM Std. Packing (pcs/ctn) 1 1 1 1 1 Packing Size (cm) 35X26X35 39X31X36 44X37X44 49X42X44 52X47X47
Detail
|
|
|
|
|
|
| 8" Ventilator | 10" Ventilator | 12" Ventilator | 14" Ventilator | 16" Ventilator | |
| Model | SHT-20 | SHT-25 | SHT-30 | APB-35 | APB-40 |
| Size | Φ8inch (20cms) | Φ10 inch (25cms) | Φ12 inch (30cms) | Φ14 inch (35cms) | Φ16 inch (40cms) |
| Input | 110-127V, 60Hz | 220-240V, 50Hz | 220-240V, 50 / 60Hz | ||
| Power (Max.) | 230-250W | 320-370W | 520-550W | 750-900W | 1100-1200W |
| Air Volume (m3/min) | 25 | 43 | 65 | 82 | 96 |
| Speeds (Max.) | 2800rpm | 2800rpm | 2800rpm | 2800rpm | 2800rpm |
| Air Flow (Max.) | 882 CFM | 1520 CFM | 2300 CFM | 2900 CFM | 3400 CFM |
| Std. Packing (pcs/ctn) | 1 | 1 | 1 | 1 | 1 |
| Packing Size (cm) | 35X26X35 | 39X31X36 | 44X37X44 | 49X42X44 | 52X47X47 |
